Description
This S7020ACD/HCP4ADBA bearing is a Super Precision angular contact bearing with 2 rubber seals, a 25° contact angle and the balls are hybrid ceramic, also known as bearing grade Silicon Nitride. This is a back to back arrangement double set of bearings with a light, preload and a P4 precision rating. The bearing's dimensions are 100x140x24. Often used in Machine Tools, or other precision applications, these bearings are known for their high-speed capabilities, robust seals, and superior accuracy.
| S | 70 | 20 | ACD | HC | P4A | DB | A | |
|---|---|---|---|---|---|---|---|---|
| Sealed | Extra Light Series | 100mm - Bore Size | 25° Contact Angle | Balls are Bearing Grade Silicon Nitride (Hybrid Bearing) | Accuracy Class | Duplex Back-to-Back | Light Preload |
Product Information
Technical Data
Inside Diameter (mm) :
100mm
Outside Diameter (mm) :
150mm
Width (mm) :
24mm
Clearance :
Standard
Cage Type :
Plastic
Dynamic Load Rating (kN) :
79.3
Grease Limiting Speed (r/min) :
9500
Oil Limiting Speed (r/min) :
15000
Static Load Rating (kN) :
80
Seals Or Shields :
Two Rubber Seals
Preload :
Light
DescriptionThis S7020ACD/HCP4ADBA bearing is a Super Precision angular contact bearing with 2 rubber seals, a 25° contact angle and the balls are hybrid ceramic, also known as bearing grade Silicon Nitride. This is a back to back arrangement double set of bearings with a light, preload and a P4 precision rating. The bearing's dimensions are 100x140x24. Often used in Machine Tools, or other precision applications, these bearings are known for their high-speed capabilities, robust seals, and superior accuracy.
Product InformationBRAND: SKU:s7020acd/hcp4adba-skf AVAILABILITY:In Stock ✅ WEIGHT:1.05 kg Technical DataInside Diameter (mm) :100mm Outside Diameter (mm) :150mm Width (mm) :24mm Clearance :Standard Cage Type :Plastic Dynamic Load Rating (kN) :79.3 Grease Limiting Speed (r/min) :9500 Oil Limiting Speed (r/min) :15000 Static Load Rating (kN) :80 Seals Or Shields :Two Rubber Seals Preload :Light | ||||||||||||||||||
