Description
This 80BER10HTSUELP3 bearing is a high speed super precision angular contact bearing with 25° contact angle, ceramic balls and a phenolic cage, this bearing is a universal fit single bearing with extra light preload and a P3 precision rating. The bearing's dimensions are 80x125x22.
| 80 | BER | 10 | H | T | SU | EL | P3 | |
|---|---|---|---|---|---|---|---|---|
| Bore Size - 80mm | 25° Contact Angle | 10 Series | Rings - Bearing Steel, Rolling Elements - Ceramics | Phenolic Resin Cage with Outer Ring Guide | Open Type | Single Universal | Extra Light | Precision Rating |
Product Information
Technical Data
Inside Diameter (mm) :
80mm
Outside Diameter (mm) :
125mm
Width (mm) :
22mm
Clearance :
Standard
Seals Or Shields :
Open Type
Cage Type :
Plastic
Dynamic Load Rating (kN) :
25.3
Oil Limiting Speed (r/min) :
24400
Preload :
Extra Light
Static Load Rating (kN) :
23.5
DescriptionThis 80BER10HTSUELP3 bearing is a high speed super precision angular contact bearing with 25° contact angle, ceramic balls and a phenolic cage, this bearing is a universal fit single bearing with extra light preload and a P3 precision rating. The bearing's dimensions are 80x125x22.
Product InformationBRAND: SKU:80ber10htsuelp3-nsk AVAILABILITY:In Stock ✅ WEIGHT:0.867 kg Technical DataInside Diameter (mm) :80mm Outside Diameter (mm) :125mm Width (mm) :22mm Clearance :Standard Seals Or Shields :Open Type Cage Type :Plastic Dynamic Load Rating (kN) :25.3 Oil Limiting Speed (r/min) :24400 Preload :Extra Light Static Load Rating (kN) :23.5 | ||||||||||||||||||
